IP 5MP network dome camera, 2.8mm, POC, EZ-HAC-D2A51-F2, 5MP, Dahua

Dahua EZ-HAC-D2A51-F2 IP network dome camera, 5MP, 2.8mm.

System Overview: Experience 5MP Full HD video and the ease of using existing cabling infrastructure with HDCVI. The Lite Series 5MP HDCVI camera features a compact design and delivers high image quality at an affordable price. It offers several motorized/fixed lens models with a multilingual OSD and switchable HD/SD output. Its structural flexibility and high cost-effectiveness make the camera an ideal choice for SMB solutions.

• Maximum 25 fps@5MP (16:9 video output)

· Switchable CVI/CVBS/AHD/TVI

• Fixed 2.8 mm lens

· Max. IR length 30m, Smart IR

· IP67, IK10, DC12V

Camera Image Sensor 5MP CMOS Maximum.

Resolution 2880 (H) × 1620 (V) Pixel 5MP

Progressive Scanning System

Electronic shutter speed PAL: 1/25s-1/100000s NTSC: 1/30s-1/100000s

Signal-to-noise ratio > 65 dB

Min. Illumination 0.01 Lux/F1.6, 30IRE, 0 Lux IR on

Illumination distance 30 m (98.4 ft)

Pan/Tilt/Rotate Range: Pan: 0°-355° Tilt: 0°-65° Rotate: 0°-355°

Illuminator on/off control: Auto; manual

Lens

Lens type: Fixed focal length

Focal length 2.8mm

Max. Aperture F1.6

Video

CVI Frame Rate: PAL: 5M@25fps; 4M@25fps; 1080P@25fps NTSC: 5M@25fps; 4M@30fps; 1080P@30fps AHD: PAL: 4M@25fps; NTSC: 4M@30 fps TVI: PAL: 4M@25 fps; NTSC: 4M@30fps CVBS: PAL: 960H; NTSC: 960H

Resolution 5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960H (960 × 576/960 × 480)

Day/Night Automatic ICR Switch

BLC BLC/HLC/DWDR

WDR DWDR

White balance Auto; manual

Gain control Auto; manual

2D Noise Reduction (NR)

Smart IR Yes

Mirror Off/On

Privacy Mask Off/On (8 areas, rectangle)

Certifications

CE LVD certifications: EN 62368-1 CE EMC: EN55032 EN55024 EN55035 EN61000-3-2 EN61000-3-3

Maximum power consumption 3.5 W (12 V DC, IR activated)

12V ±30% DC power supply (NOT INCLUDED).
